206136-1
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PLG HSG FMALE 7POS INLINE
- CategoryCircular Connectors - Housings
- Datasheet 206136-1 Datasheet
-
ECAD Model
- Share
In Stock: 167
Can ship immediately
Pricing:
- 1$9.64
- 10$9.22126
- 25$8.38289
- 50$7.96391
- 100$7.75421
- 250$6.91594
- 500$6.49681
- 1,000$5.74234
Quote It
Technical Details
- Series:CPC Series 3
- Package:Bulk
- Part Status:Active
- Connector Type:Plug Housing
- Type:For Female Sockets
- Number of Positions:7 (Power)
- Shell Size - Insert:23-7
- Shell Size, MIL:-
- Contact Type:Crimp
- Contact Size:-
- Mounting Type:Free Hanging (In-Line)
- Mounting Feature:-
- Fastening Type:Threaded
- Orientation:Keyed
- Shell Material:Polyamide (PA66), Nylon 6/6, Glass Filled
- Shell Finish:-
- Housing Color:Black
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Features:Coupling Nut
- Shielding:Unshielded
