JN1DS10SL1
JAE Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PLG HSG FMALE 10POS INLINE
- CategoryCircular Connectors - Housings
- Datasheet JN1DS10SL1 Datasheet
-
ECAD Model
- Share
In Stock: 115
Can ship immediately
Pricing:
- 1$11.55
- 10$10.5
- 25$10.2375
- 50$9.45
- 100$8.925
- 250$8.1375
- 500$7.6125
- 1,000$6.9825
Quote It
Technical Details
- Series:JN1
- Package:Tray
- Part Status:Active
- Connector Type:Plug Housing
- Type:For Female Sockets
- Number of Positions:10
- Shell Size - Insert:S
- Shell Size, MIL:-
- Contact Type:Crimp
- Contact Size:22
- Mounting Type:Free Hanging (In-Line)
- Mounting Feature:-
- Fastening Type:Push-Twist
- Orientation:N (Normal)
- Shell Material:Synthetic Resin
- Shell Finish:-
- Housing Color:Black
- Ingress Protection:IP67 - Dust Tight, Waterproof
- Material Flammability Rating:-
- Features:Backshell, Coupling Nut
- Shielding:Unshielded
