JN1HS10PL1
JAE Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RCPT HSG MALE 10POS INLINE
- CategoryCircular Connectors - Housings
- Datasheet JN1HS10PL1 Datasheet
-
ECAD Model
- Share
In Stock: 181
Can ship immediately
Pricing:
- 1$18.82
- 10$17.472
- 25$15.68
- 50$15.232
- 100$13.44
- 250$12.544
- 500$12.2752
Quote It
Technical Details
- Series:JN1
- Package:Bulk
- Part Status:Active
- Connector Type:Receptacle Housing
- Type:For Male Pins
- Number of Positions:10
- Shell Size - Insert:S
- Shell Size, MIL:-
- Contact Type:Crimp
- Contact Size:22
- Mounting Type:Free Hanging (In-Line)
- Mounting Feature:-
- Fastening Type:Push-Twist
- Orientation:N (Normal)
- Shell Material:Synthetic Resin
- Shell Finish:-
- Housing Color:Black
- Ingress Protection:IP67 - Dust Tight, Waterproof
- Material Flammability Rating:-
- Features:Backshell
- Shielding:Unshielded
