JL05-6A22-14PC-F0-R
JAE Electronics- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PLG HSG MALE 19POS INLINE
- CategoryCircular Connectors - Housings
- Datasheet JL05-6A22-14PC-F0-R Datasheet
-
ECAD Model
- Share
In Stock: 198
Can ship immediately
Pricing:
- 1$30.41071
- 14$30.41071
Quote It
Technical Details
- Series:JL05
- Package:Bulk
- Part Status:Active
- Connector Type:Plug Housing
- Type:For Male Pins
- Number of Positions:19 (18 + PE)
- Shell Size - Insert:22-14
- Shell Size, MIL:-
- Contact Type:Crimp
- Contact Size:16
- Mounting Type:Free Hanging (In-Line)
- Mounting Feature:-
- Fastening Type:Bayonet Lock
- Orientation:N (Normal)
- Shell Material:Aluminum
- Shell Finish:Zinc
- Housing Color:Black
- Ingress Protection:IP67 - Dust Tight, Waterproof
- Material Flammability Rating:UL94 V-0
- Features:Coupling Nut
- Shielding:Unshielded
