THP 3-7212

Technical Details

• Series:THP 3 (3W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):36V
• Voltage - Input (Max):160V
• Voltage - Output 1:12V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):250mA
• Power (Watts):3 W

• Voltage - Isolation:3 kV
• Applications:ITE (Commercial), Medical
• Features:SCP
• Operating Temperature:-40°C ~ 85°C (With Derating)
• Efficiency:83%
• Mounting Type:Through Hole
• Package / Case:24-DIP Module, 5 Leads
• Size / Dimension:1.25" L x 0.80" W x 0.41" H (31.8mm x 20.3mm x 10.5mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
