PEM2-S5-D5-D

Technical Details

• Series:PEM2-D (2W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):4.5V
• Voltage - Input (Max):5.5V
• Voltage - Output 1:5V
• Voltage - Output 2:-5V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):200mA, 200mA
• Power (Watts):2 W

• Voltage - Isolation:3 kV
• Applications:ITE (Commercial)
• Features:SCP
• Operating Temperature:-40°C ~ 105°C
• Efficiency:80%
• Mounting Type:Through Hole
• Package / Case:14-DIP Module, 6 Leads
• Size / Dimension:0.79" L x 0.39" W x 0.32" H (20.1mm x 9.9mm x 8.2mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:CB Scheme, EN, IEC, UL
• Standard Number:55024; 55032 Class A; 60950-1
