STH0548S7V2

Technical Details

• Series:STH05 (5W)
• Package:Tube
• Part Status:Active
• Type:Non-Isolated PoL Module
• Number of Outputs:1
• Voltage - Input (Min):14V
• Voltage - Input (Max):72V
• Voltage - Output 1:7.2V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):500mA
• Power (Watts):-

• Voltage - Isolation:-
• Applications:ITE (Commercial)
• Features:Remote On/Off, SCP
• Operating Temperature:-40°C ~ 105°C (With Derating)
• Efficiency:89%
• Mounting Type:Surface Mount
• Package / Case:10-SMD Module, 6 Leads
• Size / Dimension:0.77" L x 0.46" W x 0.20" H (19.5mm x 11.8mm x 5.0mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
