TMR 3-2421WIR
TRACO Power
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER +/-5V 3W
- CategoryDC DC Converters
- Datasheet TMR 3-2421WIR Datasheet
-
ECAD Model
- Share
In Stock: 174
Can ship immediately
Pricing:
- 1$25.6
- 10$23.664
- 25$23.2944
- 50$22.185
- 100$20.3363
- 250$19.96652
- 500$19.6707
Quote It
Technical Details
- Series:TMR 3WIR (3W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:2
- Voltage - Input (Min):9V
- Voltage - Input (Max):36V
- Voltage - Output 1:5V
- Voltage - Output 2:-5V
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):300mA, 300mA
- Power (Watts):3 W
- Voltage - Isolation:3 kV
- Applications:ITE (Commercial), Railway
- Features:Remote On/Off, SCP
- Operating Temperature:-40°C ~ 90°C (With Derating)
- Efficiency:80%
- Mounting Type:Through Hole
- Package / Case:8-SIP Module
- Size / Dimension:0.86" L x 0.38" W x 0.44" H (21.8mm x 9.6mm x 11.2mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:-
- Standard Number:-
