TIM 3.5-0919
TRACO Power
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER 9V 3.5W
- CategoryDC DC Converters
- Datasheet TIM 3.5-0919 Datasheet
-
ECAD Model
- Share
In Stock: 155
Can ship immediately
Pricing:
- 1$32.7
- 10$31.87495
- 25$31.37691
- 50$29.88277
- 100$27.39254
- 250$26.89449
- 500$23.90622
Quote It
Technical Details
- Series:TIM 3.5 (3.5W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:1
- Voltage - Input (Min):4.5V
- Voltage - Input (Max):12V
- Voltage - Output 1:9V
- Voltage - Output 2:-
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):389mA
- Power (Watts):3.5 W
- Voltage - Isolation:5 kV
- Applications:Medical
- Features:Remote On/Off, OVP, SCP
- Operating Temperature:-40°C ~ 90°C (With Derating)
- Efficiency:78%
- Mounting Type:Through Hole
- Package / Case:16-DIP Module, 7 Leads
- Size / Dimension:0.96" L x 0.57" W x 0.40" H (24.3mm x 14.4mm x 10.2mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:-
- Standard Number:-
