THN 15-7223WIR
TRACO Power
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER +/-15V 15W
- CategoryDC DC Converters
- Datasheet THN 15-7223WIR Datasheet
-
ECAD Model
- Share
In Stock: 118
Can ship immediately
Pricing:
- 1$61.9
- 10$52.17286
- 25$50.51606
- 50$48.03175
- 100$44.71921
- 250$39.75041
Quote It
Technical Details
- Series:THN 15WIR (15W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:2
- Voltage - Input (Min):36V
- Voltage - Input (Max):160V
- Voltage - Output 1:15V
- Voltage - Output 2:-15V
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):500mA, 500mA
- Power (Watts):15 W
- Voltage - Isolation:3 kV
- Applications:ITE (Commercial), Railway
- Features:Remote On/Off, OVP, SCP, UVLO
- Operating Temperature:-40°C ~ 90°C (With Derating)
- Efficiency:89%
- Mounting Type:Through Hole
- Package / Case:6-DIP Module
- Size / Dimension:1.00" L x 1.00" W x 0.39" H (25.4mm x 25.4mm x 9.9mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:-
- Standard Number:-
