AM1/4S-0505SH30Z

Technical Details

• Series:AM1/4S-Z (0.25W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):4.5V
• Voltage - Input (Max):5.5V
• Voltage - Output 1:5V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):50mA
• Power (Watts):250 mW

• Voltage - Isolation:3 kV
• Applications:ITE (Commercial)
• Features:-
• Operating Temperature:-40°C ~ 85°C
• Efficiency:71%
• Mounting Type:Through Hole
• Package / Case:4-SIP Module
• Size / Dimension:0.46" L x 0.24" W x 0.40" H (11.7mm x 6.0mm x 9.7mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:CE
• Standard Number:-
