IE1209S
XP Power
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER 9V 1W
- CategoryDC DC Converters
- Datasheet IE1209S Datasheet
-
ECAD Model
- Share
In Stock: 216
Can ship immediately
Pricing:
- 1$4.15
- 5$4.026
- 10$3.901
- 25$3.7352
- 100$3.486
Quote It
Technical Details
- Series:IE (1W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:1
- Voltage - Input (Min):10.8V
- Voltage - Input (Max):13.2V
- Voltage - Output 1:9V
- Voltage - Output 2:-
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):111mA
- Power (Watts):1 W
- Voltage - Isolation:1 kV
- Applications:ITE (Commercial)
- Features:-
- Operating Temperature:-40°C ~ 85°C
- Efficiency:77%
- Mounting Type:Through Hole
- Package / Case:4-SIP Module
- Size / Dimension:0.46" L x 0.24" W x 0.50" H (11.7mm x 6.0mm x 12.7mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:-
- Standard Number:-
