AM3GH-2415SZ
DComponents
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER 15V 3W
- CategoryDC DC Converters
-
ECAD Model
- Share
In Stock: 207
Can ship immediately
Pricing:
- 1$13.36
Quote It
Technical Details
- Series:AM3GH-Z (3W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:1
- Voltage - Input (Min):9V
- Voltage - Input (Max):36V
- Voltage - Output 1:15V
- Voltage - Output 2:-
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):200mA
- Power (Watts):3 W
- Voltage - Isolation:1.6 kV
- Applications:ITE (Commercial)
- Features:Remote On/Off
- Operating Temperature:-40°C ~ 71°C (With Derating)
- Efficiency:82%
- Mounting Type:Through Hole
- Package / Case:8-SIP Module, 7 Leads
- Size / Dimension:0.86" L x 0.36" W x 0.44" H (21.9mm x 9.2mm x 11.1mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:CE
- Standard Number:-
