ICZ0948S12
XP Power
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER 12V 9W
- CategoryDC DC Converters
- Datasheet ICZ0948S12 Datasheet
-
ECAD Model
- Share
In Stock: 175
Can ship immediately
Pricing:
- 1$24
- 5$23.28
- 10$22.56
- 25$21.6
- 100$20.16
Quote It
Technical Details
- Series:ICZ (9W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:1
- Voltage - Input (Min):36V
- Voltage - Input (Max):75V
- Voltage - Output 1:12V
- Voltage - Output 2:-
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):750mA
- Power (Watts):9 W
- Voltage - Isolation:1.6 kV
- Applications:ITE (Commercial)
- Features:Remote On/Off, OCP, SCP, UVLO
- Operating Temperature:-40°C ~ 85°C (With Derating)
- Efficiency:89%
- Mounting Type:Through Hole
- Package / Case:12-SIP Module, 6 Leads
- Size / Dimension:0.86" L x 0.38" W x 0.44" H (21.8mm x 9.6mm x 11.2mm)
- Supplier Device Package:12-SIP
- Control Features:-
- Approval Agency:-
- Standard Number:62368-1
