EC7AW-48S12

Technical Details

• Series:EC7AW (10W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):18V
• Voltage - Input (Max):74V
• Voltage - Output 1:12V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):833mA
• Power (Watts):10 W

• Voltage - Isolation:3 kV
• Applications:ITE (Commercial)
• Features:Adjustable Output, Baseplate, Remote On/Off
• Operating Temperature:-40°C ~ 105°C (With Derating)
• Efficiency:90%
• Mounting Type:Through Hole
• Package / Case:24-DIP Module, 8 Leads
• Size / Dimension:1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm)
• Supplier Device Package:-
• Control Features:Enable, Active High
• Approval Agency:CE
• Standard Number:62368-1
