TEP 40-7215UIR

Technical Details

• Series:TEP 40UIR (40W)
• Package:Box
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):14V
• Voltage - Input (Max):160V
• Voltage - Output 1:24V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):1.67A
• Power (Watts):40 W

• Voltage - Isolation:3 kV
• Applications:ITE (Commercial), Railway
• Features:Adjustable Output, Remote On/Off
• Operating Temperature:-40°C ~ 85°C
• Efficiency:90%
• Mounting Type:Through Hole
• Package / Case:Quarter Brick
• Size / Dimension:2.28" L x 1.45" W x 0.50" H (57.9mm x 36.8mm x 12.7mm)
• Supplier Device Package:Quarter Brick
• Control Features:-
• Approval Agency:CB, cURus
• Standard Number:-
