PDS1-S5-D12-M
CUI Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER +/-12V 1W
- CategoryDC DC Converters
- Datasheet PDS1-S5-D12-M Datasheet
-
ECAD Model
- Share
In Stock: 197
Can ship immediately
Pricing:
- 1$5.36
- 5$5.278
- 10$5.202
- 32$5.04906
- 64$4.89594
- 128$4.74297
- 256$4.59
- 512$4.284
Quote It
Technical Details
- Series:PDS1-M (1W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:2
- Voltage - Input (Min):4.5V
- Voltage - Input (Max):5.5V
- Voltage - Output 1:12V
- Voltage - Output 2:-12V
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):42mA, 42mA
- Power (Watts):1 W
- Voltage - Isolation:1.5 kV
- Applications:ITE (Commercial)
- Features:SCP
- Operating Temperature:-40°C ~ 105°C (With Derating)
- Efficiency:81%
- Mounting Type:Surface Mount
- Package / Case:10-SMD Module, 6 Leads
- Size / Dimension:0.60" L x 0.33" W x 0.29" H (15.2mm x 8.3mm x 7.3mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:CB Scheme, EN, IEC
- Standard Number:55024; 55032 Class A; 60950-1
