PEM2-S5-S12-S
CUI Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER 12V 2W
- CategoryDC DC Converters
- Datasheet PEM2-S5-S12-S Datasheet
-
ECAD Model
- Share
In Stock: 224
Can ship immediately
Pricing:
- 1$7.49
- 5$7.384
- 12$7.27583
- 36$7.06194
- 60$6.848
- 108$6.63398
- 252$6.42
- 504$5.992
Quote It
Technical Details
- Series:PEM2-S (2W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:1
- Voltage - Input (Min):4.5V
- Voltage - Input (Max):5.5V
- Voltage - Output 1:12V
- Voltage - Output 2:-
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):166.6mA
- Power (Watts):2 W
- Voltage - Isolation:3 kV
- Applications:ITE (Commercial)
- Features:SCP
- Operating Temperature:-40°C ~ 105°C
- Efficiency:84%
- Mounting Type:Through Hole
- Package / Case:7-SIP Module, 4 Leads
- Size / Dimension:0.77" L x 0.28" W x 0.39" H (19.6mm x 7.0mm x 10.0mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:CB Scheme, EN, IEC, UL
- Standard Number:55024; 55032 Class A; 60950-1
