DCM12S0A0S12NFA

Technical Details

• Series:Delphi DCM
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Not For New Designs
• Type:Non-Isolated PoL Module
• Number of Outputs:1
• Voltage - Input (Min):4.5V
• Voltage - Input (Max):14V
• Voltage - Output 1:0.69 ~ 5V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):12A
• Power (Watts):60 W

• Voltage - Isolation:-
• Applications:ITE (Commercial)
• Features:Remote On/Off, OCP, UVLO
• Operating Temperature:-40°C ~ 85°C
• Efficiency:95.4%
• Mounting Type:Surface Mount
• Package / Case:Module
• Size / Dimension:0.80" L x 0.45" W x 0.33" H (20.3mm x 11.4mm x 8.5mm)
• Supplier Device Package:-
• Control Features:Enable, Active Low
• Approval Agency:-
• Standard Number:-
