HQA2W085W240V-N07-S

Technical Details

• Series:HQA85 (85W)
• Package:Tray
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):9V
• Voltage - Input (Max):40V
• Voltage - Output 1:24V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):3.5A
• Power (Watts):85 W

• Voltage - Isolation:2.25 kV
• Applications:ITE (Commercial)
• Features:Remote On/Off, OCP, OVP
• Operating Temperature:-40°C ~ 115°C
• Efficiency:87%
• Mounting Type:Through Hole
• Package / Case:Quarter Brick
• Size / Dimension:2.39" L x 1.54" W x 0.50" H (60.6mm x 39.5mm x 12.7mm)
• Supplier Device Package:-
• Control Features:Enable, Active Low
• Approval Agency:CE
• Standard Number:-
