RS6-1212D
RECOM Power
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER +/-12V 6W
- CategoryDC DC Converters
- Datasheet RS6-1212D Datasheet
-
ECAD Model
- Share
In Stock: 138
Can ship immediately
Pricing:
- 1$13.46
- 5$13.35302
- 22$13.25195
- 44$13.04787
- 66$12.64012
- 110$11.41689
- 264$11.21301
- 506$11.00914
Quote It
Technical Details
- Series:ECONOLINE RS6 (6W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:2
- Voltage - Input (Min):9V
- Voltage - Input (Max):18V
- Voltage - Output 1:12V
- Voltage - Output 2:-12V
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):250mA, 250mA
- Power (Watts):6 W
- Voltage - Isolation:1.6 kV
- Applications:ITE (Commercial)
- Features:Remote On/Off, OCP, SCP, UVLO
- Operating Temperature:-40°C ~ 75°C
- Efficiency:87%
- Mounting Type:Through Hole
- Package / Case:8-SIP Module, 7 Leads
- Size / Dimension:0.86" L x 0.36" W x 0.44" H (21.8mm x 9.2mm x 11.1mm)
- Supplier Device Package:-
- Control Features:Enable, Active Low
- Approval Agency:-
- Standard Number:-
