PDS1-S24-S5-M-TR
CUI Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER 5V 1W
- CategoryDC DC Converters
- Datasheet PDS1-S24-S5-M-TR Datasheet
-
ECAD Model
- Share
In Stock: 109
Can ship immediately
Pricing:
- 1$4.5
- 500$3.598
Quote It
Technical Details
- Series:PDS1-M (1W)
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:1
- Voltage - Input (Min):21.6V
- Voltage - Input (Max):26.4V
- Voltage - Output 1:5V
- Voltage - Output 2:-
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):200mA
- Power (Watts):1 W
- Voltage - Isolation:1.5 kV
- Applications:ITE (Commercial)
- Features:SCP
- Operating Temperature:-40°C ~ 105°C (With Derating)
- Efficiency:80%
- Mounting Type:Surface Mount
- Package / Case:8-SMD Module, 5 Leads
- Size / Dimension:0.50" L x 0.33" W x 0.29" H (12.7mm x 8.3mm x 7.3mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:EN, UL
- Standard Number:55024; 55032 Class A; 60950-1
