IZ0505SA
XP Power
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER 5V 3W
- CategoryDC DC Converters
- Datasheet IZ0505SA Datasheet
-
ECAD Model
- Share
In Stock: 149
Can ship immediately
Pricing:
- 1$13.25
- 5$12.852
- 10$12.455
- 25$11.9252
- 100$11.1301
Quote It
Technical Details
- Series:IZ (3W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:1
- Voltage - Input (Min):4.5V
- Voltage - Input (Max):9V
- Voltage - Output 1:5V
- Voltage - Output 2:-
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):600mA
- Power (Watts):3 W
- Voltage - Isolation:1.6 kV
- Applications:ITE (Commercial)
- Features:Remote On/Off, SCP
- Operating Temperature:-40°C ~ 100°C
- Efficiency:76%
- Mounting Type:Through Hole
- Package / Case:8-SIP Module, 7 Leads
- Size / Dimension:0.86" L x 0.36" W x 0.44" H (21.9mm x 9.2mm x 11.1mm)
- Supplier Device Package:-
- Control Features:Enable, Active Low
- Approval Agency:-
- Standard Number:62368-1
