TMR 6-7212WIR
TRACO Power
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER 12V 6W
- CategoryDC DC Converters
- Datasheet TMR 6-7212WIR Datasheet
-
ECAD Model
- Share
In Stock: 180
Can ship immediately
Pricing:
- 1$31.6
- 10$29.168
- 25$28.7124
- 50$27.345
- 100$25.0663
- 250$24.61052
- 500$21.876
Quote It
Technical Details
- Series:TMR 6WIR (6W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:1
- Voltage - Input (Min):43V
- Voltage - Input (Max):160V
- Voltage - Output 1:12V
- Voltage - Output 2:-
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):500mA
- Power (Watts):6 W
- Voltage - Isolation:3 kV
- Applications:ITE (Commercial), Railway
- Features:Remote On/Off, OCP, SCP
- Operating Temperature:-40°C ~ 80°C (With Derating)
- Efficiency:86%
- Mounting Type:Through Hole
- Package / Case:8-SIP Module
- Size / Dimension:0.86" L x 0.38" W x 0.44" H (21.8mm x 9.6mm x 11.2mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:-
- Standard Number:-
