PDM1-S5-D9-S
CUI Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER +/-9V 1W
- CategoryDC DC Converters
- Datasheet PDM1-S5-D9-S Datasheet
-
ECAD Model
- Share
In Stock: 176
Can ship immediately
Pricing:
- 1$4.5
- 5$4.434
- 12$4.36917
- 36$4.24056
- 60$4.112
- 108$3.98352
- 252$3.855
- 504$3.598
Quote It
Technical Details
- Series:PDM1-S (1W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:2
- Voltage - Input (Min):4.5V
- Voltage - Input (Max):5.5V
- Voltage - Output 1:9V
- Voltage - Output 2:-9V
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):56mA, 56mA
- Power (Watts):1 W
- Voltage - Isolation:1.5 kV
- Applications:ITE (Commercial)
- Features:SCP
- Operating Temperature:-40°C ~ 105°C
- Efficiency:80%
- Mounting Type:Through Hole
- Package / Case:6-SIP Module, 5 Leads
- Size / Dimension:0.77" L x 0.24" W x 0.37" H (19.5mm x 6.0mm x 9.3mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:CB Scheme, EN, IEC, UL
- Standard Number:55024; 55032 Class A; 60950-1
