PEM1-S24-D12-S
CUI Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER +/-12V 1W
- CategoryDC DC Converters
- Datasheet PEM1-S24-D12-S Datasheet
-
ECAD Model
- Share
In Stock: 160
Can ship immediately
Pricing:
- 1$5.14
- 5$5.06215
- 10$4.9883
- 25$4.84178
- 50$4.69487
- 100$4.54815
- 250$4.40144
- 500$4.10801
Quote It
Technical Details
- Series:PEM1-S (1W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:2
- Voltage - Input (Min):21.6V
- Voltage - Input (Max):26.4V
- Voltage - Output 1:12V
- Voltage - Output 2:-12V
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):42mA, 42mA
- Power (Watts):1 W
- Voltage - Isolation:3 kV
- Applications:ITE (Commercial)
- Features:SCP
- Operating Temperature:-40°C ~ 105°C
- Efficiency:81%
- Mounting Type:Through Hole
- Package / Case:7-SIP Module, 5 Leads
- Size / Dimension:0.77" L x 0.24" W x 0.37" H (19.5mm x 6.0mm x 9.3mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:CB Scheme, EN, IEC, UL
- Standard Number:55024; 55032 Class A; 60950-1
