SMU02M-12
MEAN WELL
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER 12V 2W
- CategoryDC DC Converters
- Datasheet SMU02M-12 Datasheet
-
ECAD Model
- Share
In Stock: 231
Can ship immediately
Pricing:
- 1$5.3
- 10$5.14619
- 25$4.99474
- 50$4.84348
Quote It
Technical Details
- Series:SMU02 (2W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:1
- Voltage - Input (Min):10.8V
- Voltage - Input (Max):13.2V
- Voltage - Output 1:12V
- Voltage - Output 2:-
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):167mA
- Power (Watts):2 W
- Voltage - Isolation:1.5 kV
- Applications:ITE (Commercial)
- Features:OCP, SCP
- Operating Temperature:-40°C ~ 85°C (With Derating)
- Efficiency:85%
- Mounting Type:Through Hole
- Package / Case:4-SIP Module
- Size / Dimension:0.46" L x 0.30" W x 0.40" H (11.6mm x 7.5mm x 10.1mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:-
- Standard Number:-
