SPU03M-12
MEAN WELL
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER 12V 3W
- CategoryDC DC Converters
- Datasheet SPU03M-12 Datasheet
-
ECAD Model
- Share
In Stock: 173
Can ship immediately
Pricing:
- 1$6.62
- 10$6.43058
- 25$6.24116
- 50$6.05213
Quote It
Technical Details
- Series:SPU03 (3W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:1
- Voltage - Input (Min):10.8V
- Voltage - Input (Max):13.2V
- Voltage - Output 1:12V
- Voltage - Output 2:-
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):250mA
- Power (Watts):3 W
- Voltage - Isolation:3 kV
- Applications:ITE (Commercial)
- Features:OCP, SCP
- Operating Temperature:-40°C ~ 90°C (With Derating)
- Efficiency:86%
- Mounting Type:Through Hole
- Package / Case:7-SIP Module, 4 Leads
- Size / Dimension:0.77" L x 0.30" W x 0.40" H (19.6mm x 7.5mm x 10.2mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:-
- Standard Number:-
