DPBW06F-15
MEAN WELL
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER +/-15V 6W
- CategoryDC DC Converters
- Datasheet DPBW06F-15 Datasheet
-
ECAD Model
- Share
In Stock: 181
Can ship immediately
Pricing:
- 1$10.35
- 10$10.18994
- 25$10.03341
- 50$9.71997
Quote It
Technical Details
- Series:DPBW06 (6W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:2
- Voltage - Input (Min):9V
- Voltage - Input (Max):36V
- Voltage - Output 1:15V
- Voltage - Output 2:-15V
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):200mA, 200mA
- Power (Watts):6 W
- Voltage - Isolation:1.5 kV
- Applications:ITE (Commercial)
- Features:Remote On/Off, OCP, SCP
- Operating Temperature:-40°C ~ 85°C (With Derating)
- Efficiency:88%
- Mounting Type:Through Hole
- Package / Case:8-SIP Module, 7 Leads
- Size / Dimension:0.86" L x 0.36" W x 0.44" H (21.8mm x 9.2mm x 11.1mm)
- Supplier Device Package:-
- Control Features:Enable, Active Low
- Approval Agency:-
- Standard Number:-
