PQMC1-D12-D12-S

Technical Details

• Series:PQMC1-S (1W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):9V
• Voltage - Input (Max):18V
• Voltage - Output 1:12V
• Voltage - Output 2:-12V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):41mA, 41mA
• Power (Watts):1 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:OCP, SCP
• Operating Temperature:-40°C ~ 105°C
• Efficiency:80%
• Mounting Type:Through Hole
• Package / Case:8-SIP Module, 7 Leads
• Size / Dimension:0.87" L x 0.37" W x 0.47" H (22.0mm x 9.5mm x 12.0mm)
• Supplier Device Package:-
• Control Features:Enable, Active Low
• Approval Agency:EN
• Standard Number:55024; 55032 Class A
