PDQ2-D5-S15-S
CUI Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER 15V 2W
- CategoryDC DC Converters
- Datasheet PDQ2-D5-S15-S Datasheet
-
ECAD Model
- Share
In Stock: 136
Can ship immediately
Pricing:
- 1$11.35
- 5$11.266
- 14$11.18
- 28$11.00786
- 56$10.66393
- 112$9.63196
- 252$9.46
- 504$9.288
Quote It
Technical Details
- Series:PDQ2-S (2W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:1
- Voltage - Input (Min):4.5V
- Voltage - Input (Max):9V
- Voltage - Output 1:15V
- Voltage - Output 2:-
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):134mA
- Power (Watts):2 W
- Voltage - Isolation:1.5 kV
- Applications:ITE (Commercial)
- Features:Remote On/Off, OCP, SCP
- Operating Temperature:-40°C ~ 100°C
- Efficiency:80%
- Mounting Type:Through Hole
- Package / Case:8-SIP Module, 7 Leads
- Size / Dimension:0.86" L x 0.36" W x 0.44" H (21.8mm x 9.1mm x 11.2mm)
- Supplier Device Package:-
- Control Features:Enable, Active Low
- Approval Agency:EN
- Standard Number:55032 Class A
