EC2SB-24S05
Cincon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER 5V 10W
- CategoryDC DC Converters
-
ECAD Model
- Share
In Stock: 157
Can ship immediately
Pricing:
- 1$24.99
- 10$24.74052
- 25$24.24538
- 50$23.51808
- 100$22.34205
- 500$17.83379
Quote It
Technical Details
- Series:EC2SB (10W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:1
- Voltage - Input (Min):18V
- Voltage - Input (Max):36V
- Voltage - Output 1:5V
- Voltage - Output 2:-
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):2A
- Power (Watts):10 W
- Voltage - Isolation:1.5 kV
- Applications:ITE (Commercial)
- Features:Remote On/Off, OCP, OVP, SCP, UVLO
- Operating Temperature:-40°C ~ 85°C (With Derating)
- Efficiency:85%
- Mounting Type:Through Hole
- Package / Case:6-DIP Module
- Size / Dimension:1.00" L x 1.00" W x 0.40" H (25.4mm x 25.4mm x 10.2mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:-
- Standard Number:-
