EC4BW04
Cincon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER +/-12V 10W
- CategoryDC DC Converters
-
ECAD Model
- Share
In Stock: 165
Can ship immediately
Pricing:
- 1$30.75
- 5$30.443
- 10$30.13803
- 25$29.53535
- 50$28.64931
- 100$27.21693
Quote It
Technical Details
- Series:EC4BW (10W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:2
- Voltage - Input (Min):9V
- Voltage - Input (Max):36V
- Voltage - Output 1:12V
- Voltage - Output 2:-12V
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):415mA, 415mA
- Power (Watts):10 W
- Voltage - Isolation:500 V
- Applications:ITE (Commercial)
- Features:SCP
- Operating Temperature:-40°C ~ 100°C (With Derating)
- Efficiency:80%
- Mounting Type:Through Hole
- Package / Case:5-DIP Module
- Size / Dimension:2.00" L x 1.00" W x 0.40" H (50.8mm x 25.4mm x 10.2mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:-
- Standard Number:-
