TEN 8-4823WI
TRACO Power
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER +/-15V 8W
- CategoryDC DC Converters
- Datasheet TEN 8-4823WI Datasheet
-
ECAD Model
- Share
In Stock: 167
Can ship immediately
Pricing:
- 1$36.3
- 10$34.736
- 25$34.1932
- 50$32.565
- 100$29.8513
- 250$29.30852
- 500$26.052
Quote It
Technical Details
- Series:TEN 8WI (8W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:2
- Voltage - Input (Min):18V
- Voltage - Input (Max):75V
- Voltage - Output 1:15V
- Voltage - Output 2:-15V
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):267mA, 267mA
- Power (Watts):8 W
- Voltage - Isolation:1.5 kV
- Applications:ITE (Commercial), Railway
- Features:Remote On/Off, OCP, OVP, SCP, UVLO
- Operating Temperature:-40°C ~ 85°C (With Derating)
- Efficiency:87%
- Mounting Type:Through Hole
- Package / Case:24-DIP Module, 9 Leads
- Size / Dimension:1.26" L x 0.80" W x 0.40" H (32.0mm x 20.3mm x 10.2mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:-
- Standard Number:-
