DPAN02A-15
MEAN WELL
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER +/-15V 2W
- CategoryDC DC Converters
- Datasheet DPAN02A-15 Datasheet
-
ECAD Model
- Share
In Stock: 163
Can ship immediately
Pricing:
- 1$8.14
- 10$7.90935
- 25$7.67639
- 50$7.44382
Quote It
Technical Details
- Series:DPAN02 (2W)
- Package:-
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:2
- Voltage - Input (Min):9V
- Voltage - Input (Max):18V
- Voltage - Output 1:15V
- Voltage - Output 2:-15V
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):67mA, 67mA
- Power (Watts):2 W
- Voltage - Isolation:1.5 kV
- Applications:ITE (Commercial)
- Features:Remote On/Off, OCP, SCP, UVLO
- Operating Temperature:-40°C ~ 90°C (With Derating)
- Efficiency:83%
- Mounting Type:Through Hole
- Package / Case:8-SIP Module, 7 Leads
- Size / Dimension:0.86" L x 0.36" W x 0.44" H (21.8mm x 9.2mm x 11.1mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:-
- Standard Number:-
