DLC03B-15
MEAN WELL
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER +/-15V 3W
- CategoryDC DC Converters
- Datasheet DLC03B-15 Datasheet
-
ECAD Model
- Share
In Stock: 209
Can ship immediately
Pricing:
- 1$9.81
- 10$9.65852
- 25$9.50993
- 50$9.21274
Quote It
Technical Details
- Series:DLC03 (3W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:2
- Voltage - Input (Min):18V
- Voltage - Input (Max):36V
- Voltage - Output 1:15V
- Voltage - Output 2:-15V
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):100mA, 100mA
- Power (Watts):3 W
- Voltage - Isolation:1.5 kV
- Applications:ITE (Commercial)
- Features:OCP, SCP, UVLO
- Operating Temperature:-40°C ~ 85°C (With Derating)
- Efficiency:80%
- Mounting Type:Through Hole
- Package / Case:16-DIP Module, 6 Leads
- Size / Dimension:0.87" L x 0.54" W x 0.34" H (22.1mm x 13.8mm x 8.6mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:-
- Standard Number:-
