EC4A22H-E
Cincon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER 12V 6W
- CategoryDC DC Converters
-
ECAD Model
- Share
In Stock: 164
Can ship immediately
Pricing:
- 1$12.92
- 5$12.79102
- 10$12.66313
- 25$12.40976
- 50$12.03746
- 100$11.55586
Quote It
Technical Details
- Series:EC4A-E (6W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:1
- Voltage - Input (Min):36V
- Voltage - Input (Max):72V
- Voltage - Output 1:12V
- Voltage - Output 2:-
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):500mA
- Power (Watts):6 W
- Voltage - Isolation:3 kV
- Applications:ITE (Commercial)
- Features:SCP, UVLO
- Operating Temperature:-40°C ~ 100°C (With Derating)
- Efficiency:87%
- Mounting Type:Through Hole
- Package / Case:24-DIP Module, 14 Leads
- Size / Dimension:1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:-
- Standard Number:-
