DLW05C-15

Technical Details

• Series:DLW05 (5W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):36V
• Voltage - Input (Max):72V
• Voltage - Output 1:15V
• Voltage - Output 2:-15V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):167mA, 167mA
• Power (Watts):5 W

• Voltage - Isolation:1 kV
• Applications:ITE (Commercial)
• Features:OCP, SCP
• Operating Temperature:-25°C ~ 71°C (With Derating)
• Efficiency:85%
• Mounting Type:Through Hole
• Package / Case:5-DIP Module
• Size / Dimension:2.00" L x 1.00" W x 0.44" H (50.8mm x 25.4mm x 11.3mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
