AM1DS-0509DH30JZ
DComponents
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER 9V -9V 1W
- CategoryDC DC Converters
-
ECAD Model
- Share
In Stock: 144
Can ship immediately
Pricing:
- 1$2.33
Quote It
Technical Details
- Series:AM1DS-JZ (1W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:2
- Voltage - Input (Min):4.5V
- Voltage - Input (Max):5.5V
- Voltage - Output 1:9V
- Voltage - Output 2:-9V
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):56mA, 56mA
- Power (Watts):1 W
- Voltage - Isolation:3 kV
- Applications:ITE (Commercial)
- Features:-
- Operating Temperature:-40°C ~ 85°C (With Derating)
- Efficiency:83%
- Mounting Type:Through Hole
- Package / Case:6-SIP Module, 5 Leads
- Size / Dimension:0.77" L x 0.24" W x 0.40" H (19.7mm x 6.0mm x 10.2mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:cULus, cURus
- Standard Number:-
