AM1LS-2415DH30-NZ

Technical Details

• Series:AM1LS-NZ (1W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):21.6V
• Voltage - Input (Max):26.4V
• Voltage - Output 1:15V
• Voltage - Output 2:-15V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):33mA, 33mA
• Power (Watts):1 W

• Voltage - Isolation:3 kV
• Applications:ITE (Commercial)
• Features:-
• Operating Temperature:-40°C ~ 100°C (With Derating)
• Efficiency:82%
• Mounting Type:Surface Mount
• Package / Case:10-SMD Module, 6 Leads
• Size / Dimension:0.60" L x 0.44" W x 0.28" H (15.2mm x 11.2mm x 7.3mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:cULus, cURus
• Standard Number:-
