AM2DS-2412S-NZ

Technical Details

• Series:AM2DS-NZ (2W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):21.6V
• Voltage - Input (Max):26.4V
• Voltage - Output 1:12V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):167mA
• Power (Watts):2 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:-
• Operating Temperature:-40°C ~ 85°C (With Derating)
• Efficiency:86%
• Mounting Type:Through Hole
• Package / Case:7-SIP Module, 4 Leads
• Size / Dimension:0.77" L x 0.27" W x 0.39" H (19.6mm x 7.0mm x 10.0mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:cULus, cURus
• Standard Number:-
