AM1DR-1224S-NZ

Technical Details

• Series:AM1DR-NZ (1W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):11.4V
• Voltage - Input (Max):12.6V
• Voltage - Output 1:24V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):42mA
• Power (Watts):1 W

• Voltage - Isolation:1 kV
• Applications:ITE (Commercial)
• Features:-
• Operating Temperature:-40°C ~ 85°C (With Derating)
• Efficiency:68%
• Mounting Type:Through Hole
• Package / Case:7-SIP Module, 4 Leads
• Size / Dimension:0.77" L x 0.24" W x 0.40" H (19.6mm x 6.0mm x 10.2mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:cULus, cURus
• Standard Number:-
