PQME1-S5-S9-M

Technical Details

• Series:PQME1-M (1W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):4.75V
• Voltage - Input (Max):5.25V
• Voltage - Output 1:9V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):83mA
• Power (Watts):747 mW

• Voltage - Isolation:3 kV
• Applications:ITE (Commercial)
• Features:SCP
• Operating Temperature:-40°C ~ 85°C (With Derating)
• Efficiency:72%
• Mounting Type:Surface Mount
• Package / Case:8-SMD Module, 5 Leads
• Size / Dimension:0.52" L x 0.33" W x 0.29" H (13.2mm x 8.5mm x 7.3mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:EN
• Standard Number:55024; 55032 Class A
