AM2M-2412D-NZ

Technical Details

• Series:AM2M-NZ (2W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):21.6V
• Voltage - Input (Max):26.4V
• Voltage - Output 1:12V
• Voltage - Output 2:-12V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):83mA, 83mA
• Power (Watts):2 W

• Voltage - Isolation:1.5 kV
• Applications:ITE (Commercial)
• Features:-
• Operating Temperature:-40°C ~ 85°C
• Efficiency:83%
• Mounting Type:Through Hole
• Package / Case:14-DIP Module, 6 Leads
• Size / Dimension:0.80" L x 0.40" W x 0.32" H (20.3mm x 10.2mm x 8.2mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:cURus, UL
• Standard Number:-
