1T8F_0503S4.2U

Technical Details

• Series:1T8F_4.2U (1W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):4.5V
• Voltage - Input (Max):5.5V
• Voltage - Output 1:3.3V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):303mA
• Power (Watts):1 W

• Voltage - Isolation:4.2 kV
• Applications:ITE (Commercial)
• Features:-
• Operating Temperature:-40°C ~ 105°C
• Efficiency:-
• Mounting Type:Surface Mount
• Package / Case:8-SMD Module, 5 Leads
• Size / Dimension:0.50" L x 0.44" W x 0.27" H (12.7mm x 11.2mm x 6.9mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:-
• Standard Number:-
