AM1D-121818DZ

Technical Details

• Series:AM1D-Z (1W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):10.8V
• Voltage - Input (Max):13.2V
• Voltage - Output 1:18V
• Voltage - Output 2:18V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):27mA, 27mA
• Power (Watts):972 mW

• Voltage - Isolation:1 kV
• Applications:ITE (Commercial)
• Features:-
• Operating Temperature:-40°C ~ 85°C
• Efficiency:75%
• Mounting Type:Through Hole
• Package / Case:7-SIP Module, 6 Leads
• Size / Dimension:0.77" L x 0.24" W x 0.39" H (19.5mm x 6.0mm x 10.0mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:CE, cULus, cURus
• Standard Number:-
