1T8A_0505S3.5UP

Technical Details

• Series:1T8A_3.5P (1W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:1
• Voltage - Input (Min):4.5V
• Voltage - Input (Max):5.5V
• Voltage - Output 1:5V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):200mA
• Power (Watts):1 W

• Voltage - Isolation:3.5 kV
• Applications:ITE (Commercial)
• Features:-
• Operating Temperature:-50°C ~ 125°C (With Derating)
• Efficiency:85%
• Mounting Type:Surface Mount
• Package / Case:8-SMD Module, 5 Leads
• Size / Dimension:0.50" L x 0.33" W x 0.29" H (12.7mm x 8.3mm x 7.3mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:CE
• Standard Number:-
