R1D12-2409/HP-R
RECOM Power
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER +/-9V 1W
- CategoryDC DC Converters
- Datasheet R1D12-2409/HP-R Datasheet
-
ECAD Model
- Share
In Stock: 136
Can ship immediately
Pricing:
- 1$8.56278
- 500$8.56278
Quote It
Technical Details
- Series:ECONOLINE R1D (1W)
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:2
- Voltage - Input (Min):21.6V
- Voltage - Input (Max):26.4V
- Voltage - Output 1:9V
- Voltage - Output 2:-9V
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):56mA, 56mA
- Power (Watts):1 W
- Voltage - Isolation:3 kV
- Applications:ITE (Commercial), Medical
- Features:SCP
- Operating Temperature:-40°C ~ 100°C
- Efficiency:78%
- Mounting Type:Surface Mount
- Package / Case:12-SMD Module, 10 Leads
- Size / Dimension:0.60" L x 0.42" W x 0.28" H (15.2mm x 10.7mm x 7.0mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:-
- Standard Number:-
