IR0505S
XP Power
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC DC CONVERTER +/-5V 3W
- CategoryDC DC Converters
- Datasheet IR0505S Datasheet
-
ECAD Model
- Share
In Stock: 145
Can ship immediately
Pricing:
- 1$10.5
- 5$10.186
- 10$9.87
- 25$9.45
- 100$8.8201
Quote It
Technical Details
- Series:IR (3W)
- Package:Tube
- Part Status:Active
- Type:Isolated Module
- Number of Outputs:2
- Voltage - Input (Min):4.5V
- Voltage - Input (Max):5.5V
- Voltage - Output 1:5V
- Voltage - Output 2:-5V
- Voltage - Output 3:-
- Voltage - Output 4:-
- Current - Output (Max):300mA
- Power (Watts):3 W
- Voltage - Isolation:1 kV
- Applications:ITE (Commercial)
- Features:-
- Operating Temperature:-40°C ~ 85°C
- Efficiency:82%
- Mounting Type:Through Hole
- Package / Case:7-SIP Module, 5 Leads
- Size / Dimension:0.77" L x 0.28" W x 0.39" H (19.5mm x 7.2mm x 10.0mm)
- Supplier Device Package:-
- Control Features:-
- Approval Agency:-
- Standard Number:-
