AM2D-4807DH52Z

Technical Details

• Series:AM2D-Z (2W)
• Package:Tube
• Part Status:Active
• Type:Isolated Module
• Number of Outputs:2
• Voltage - Input (Min):43.2V
• Voltage - Input (Max):52.8V
• Voltage - Output 1:7.2V
• Voltage - Output 2:-7.2V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):139mA, 139mA
• Power (Watts):2 W

• Voltage - Isolation:5.2 kV
• Applications:ITE (Commercial)
• Features:-
• Operating Temperature:-40°C ~ 85°C
• Efficiency:77%
• Mounting Type:Through Hole
• Package / Case:7-SIP Module, 5 Leads
• Size / Dimension:0.76" L x 0.28" W x 0.39" H (19.5mm x 7.2mm x 10.0mm)
• Supplier Device Package:-
• Control Features:-
• Approval Agency:CE
• Standard Number:-
